  1. Which of the following gates will have an output of 1?

    1. D
    2. A
    3. B
    4. C
Correct Option: D

(a) is a NAND gate so output is
1 × 1 = 1 = 0
(b) is a NOR gate so output is 0 + 1 = 1 = 0
(c) is a NAND gate so output is 0 × 1= 0 = 1
(d) is a XOR gate so output is 0 ⊕ 0 = 0

Following is NAND Gate
y = A . B
