If the J-input of a J-K flip-flop is treated as input and an inverter is wired between J and K inputs, the J-K flip-flop becomes—

1. R-S flip-flop
2. D flip-flop
3. T flip-flop
4. D latch

Correct Option: B

The above circuit becomes D flip-flop.
